Question # 1
You have an Azure virtual network that contains the subnets shown in the following table.
You deploy an Azure firewall to AzureFirewallSubnet. You route all traffic from Subnet2 through the firewall.
You need to ensure that all the hosts on Subnet2 can access an external site located at https://*.contoso.com.
What should you do? | | A. Create a network security group (NSG) and associate the NSG to Subnet2. | | B. In a firewall policy, create an application rule. | | C. In a firewall policy, create a DNAT rule. | | D. In a firewall policy, create a network rule. |
B. In a firewall policy, create an application rule.
Question # 2
You have the Azure load balancer shown in the Load Balancer exhibit.
You need to ensure that LB2 distributes traffic to all the members of VMSS1.
Which two actions should you perform? Each correct answer presents part of the solution.
NOTE: Each correct selection is worth one point. | | A. Add a network interface to VMSS1. | | B. Configure a health probe. | | C. Add a public IP address to each member of VMSS1. | | D. Add a load balancing rule. |
B. Configure a health probe. D. Add a load balancing rule.
Question # 3
You have an Azure subscription that contains the resources shown in the following table.
Subshell contains Three virtual machines that host an app named App1. App1 is accessed by using the SFTP protocol.
From NSG1. you configure an inbound security rule named Rule2 that allows inbound SFTP connections to ASG1.
You need to ensure that the inbound SFTP connections are managed by using ASG1. The solution must minimize administrative effort.
What should you do? | | A. From NSG1. modify the priority of Rule2. | | B. From each virtual machine, associate the network interface to ASG1 | | C. From Subnet1 create a subnet delegation. | | D. From ASG1, modify the role assignments. |
B. From each virtual machine, associate the network interface to ASG1
Question # 4
You have an Azure application gateway configured for a single website that is available at https://www.contoso.com.
The application gateway contains one backend pool and one rule. The backend pool contains two backend servers. Each backend server has an additional website that is available on port 8080.
You need to ensure that if port 8080 is unavailable on a backend server, all the traffic for https://www.contoso.com is redirected to the other backend server.
What should you do? | | A. Create a health probe. | | B. Add a new rule. | | C. Add a new listener. | | D. Change the port on the listener. |
A. Create a health probe.
Question # 5
You have the Azure resources shown in the following table.
You need to link VNei2 to Circuit1
What should you create in each subscription? To answer, select the appropriate options in the answer area.
NOTE: Each correct selection is worth one point.
|
Question # 6
Task 1
You plan to deploy a firewall to subnetl-2. The firewall will have an IP address of 10.1.2.4.
You need to ensure that traffic from subnetl-1 to the IP address range of 192.168.10.0/24 is routed through the firewall that will be deployed to subnetl-2. The solution must be achieved without using dynamic routing protocols. |
Answer: See the Explanation below for step by step instructions.
Explanation:
To deploy a firewall to subnetl-2, you need to create a network virtual appliance (NVA) in the same virtual network as subnetl-2. An NVA is a virtual machine that performs network functions, such as firewall, routing, or load balancing1.
To create an NVA, you need to create a virtual machine in the Azure portal and select an image that has the firewall software installed. You can choose from the Azure Marketplace or upload your own image2.
To assign the IP address of 10.1.2.4 to the NVA, you need to create a static private IP address for the network interface of the virtual machine. You can do this in the IP configurations settings of the network interface3.
To ensure that traffic from subnetl-1 to the IP address range of 192.168.10.0/24 is routed through the NVA, you need to create a user-defined route (UDR) table and associate it with subnetl-1. A UDR table allows you to override the default routing behavior of Azure and specify custom routes for your subnets4.
To create a UDR table, you need to go to the Route tables service in the Azure portal and select + Create. You can give a name and a resource group for the route table5.
To create a custom route, you need to select Routes in the route table and select + Add. You can enter the following information for the route5:
To associate the route table with subnetl-1, you need to select Subnets in the route table and select + Associate. You can select the virtual network and subnet that you want to associate with the route table5.
Question # 7
Task 10
You need to configure VNET1 to log all events and metrics. The solution must ensure that you can query the events and metrics directly from the Azure portal by using KQL. |
Answer: See the Explanation below for step by step instructions.
Explanation:
Here are the steps and explanations for configuring VNET1 to log all events and metrics and query them by using KQL:
To enable logging for VNET1, you need to create a diagnostic setting that collects
the platform metrics and logs from the virtual network and routes them to one or more destinations. You can choose to send the data to a Log Analytics workspace, a storage account, an event hub, or a partner solution1.
To create a diagnostic setting, you need to go to the Azure portal and select your virtual network. Then select Diagnostic settings under Monitoring and select + Add diagnostic setting1.
On the Add diagnostic setting page, enter or select the following information: Select Save to create your diagnostic setting1.
To query the events and metrics from the Azure portal by using KQL, you need to go to the Log Analytics workspace that you selected as the destination. Then select Logs under General and enter your KQL query in the query editor3.
For example, you can use the following KQL query to get the top 10 network security group events for VNET1 in the last 24 hours:
NetworkSecurityGroupEvent
| where TimeGenerated > ago(24h)
| where ResourceId contains "VNET1"
| summarize count() by EventID
| top 10 by count_ Copy
Select Run to execute your query and view the results in a table or a chart3.
